AMD Athlon 1333 Thunderbird A1333AMS3C


1 in stock

SKU: A1333AMS3C Category:
Weight: .2 lbs


This is a used AMD Athlon 1333 Thunderbird A1333AMS3C processor for Socket A (462) motherboards. Item was tested and fully working and is guaranteed against DOA. CPU posted correctly to BIOS. These processors have straight pins and may have left-over paste residue from previous installations. Great for project system or to upgrade that older system. Please ensure compatibility before purchasing.

General information
Type CPU / Microprocessor
Market segment Desktop
Family AMD Athlon
CPU part number A1333AMS3C
Stepping codes AYHJA   AYHJAR
Frequency (MHz) 1333
Bus speed (MHz) 266
Clock multiplier 10
Package 453-pin staggered ceramic PGA
1.95″ x 1.95″ (4.95 cm x 4.95 cm)
AMD Package number 27016
Socket Socket A (Socket 462)
Introduction date 21-Mar-01
Price at introduction $350
Architecture / Microarchitecture
Processor core Thunderbird (Model 4)
Manufacturing process 0.18 micron
37 million transistors
Die size 120 mm2
Floating Point Unit Integrated
Level 1 cache size 64 KB 2-way set associative code cache
64 KB 2-way set associative data cache
Level 2 cache size Full-speed on-die 256 KB
  • MMX technology
  • Enhanced 3DNow! Technology with 24 new instructions
Low power features
  • Halt state
  • Stop Grant states
  • Sleep state
  • Probe state
Electrical/Thermal parameters
V core (V) 1.75 ± 0.1
Minimum/Maximum operating temperature (°C) 0 – 95
Minimum/Typical/Maximum power dissipation (W) 5 (Stop Grant mode) / 62.6 / 69.8
Notes on AMD A1333AMS3C
  • Actual bus frequency is 133 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 266 MHz.
